Size: 10.1 inch
Brightness: 1000 nits
Contrast Ratio: 1000:1
Resolution: 1280*800
Operating Temperature: -10 - 50°C
አነስተኛ መጠን ያለው የውጭ ጉዳይ ማሳያዎች, 10.1 ኢንች ቲች 1000 NCH LCD MATS. በማያ ገጹ ላይ የሚታየው ይዘት በጥሩ ሁኔታ በሚገኝበት አካባቢ በግልጽ ማየት ይችላል, ይህም ሁሉንም የኃይል መሙያ ክምችት, ራስን ማገገገን ማሽኖች, ኪዮስኮች እና ሌሎች የአገልጋይ ተርሚናል.
ሌሎች ፍላጎቶች ካሉዎት እባክዎን እኛን ያነጋግሩን, እኛ እንደ ፍላጎቶችዎ መሠረት በጣም ተስማሚ የሆነውን ፈሳሽ የማሳያ መፍትሄ ያበጃሉ.
የተካተተ የወጪ ወጪ የምርት ባህሪን ያሳያል
10.1 "TFT LCD ፓነል
1280 * 800 ጥራት
ከቤት ውጭ ጥቅም ላይ የዋለው, ከ 500Nues እስከ 1500 የሚደርሱ ጎጆዎች
አቅም የሌለው የመነካካት ፓነል, ለ VOand ማረጋገጫ ጠንካራ እና አስተማማኝ
VGA HDI DDI USB በይነገጽ
ከፍተኛ አፈፃፀም ዋና ሰሌዳ, 7/24 ቀጣይነት ያለው ክወና
12-24V ሰፊ voltage ልቴጅ ይደግፉ
እጅግ በጣም ቀጭን የፊት ለፊት Bazel 3 ሚሜ
የፊት ፓነል ip55 የውሃ መከላከያ አቧራ መከላከል
ሰፊ የሙቀት ሥራ አሠራር -10 - 50 ° ሴ
|
Product specification |
|
|
LCD panel |
|
|
Panel size |
10.1" |
|
Resolution |
1280*800 or 1024*600 |
|
Support Color |
16.7M colors |
|
Brightness (cd/m²) |
1000 nits (can be customized) |
|
Contrast ratio |
1000:1 |
|
View angle |
80°/80°/80°/80° (R/L/U/D) |
|
Touch panel |
|
|
Touchscreen Type |
Capacitive Touch (10 points ) |
|
Surface Hardness |
7H |
|
Luminousness |
90% |
|
Touch Interface |
USB (RS232 optional) |
|
Touch response time |
2ms |
|
Working Life |
>50 million times |
|
OSD |
|
|
OSD control |
Brightness, contrast ratio, auto adjustment, H/V position, language select, etc. |
|
Support languages |
English, French, Spanish, Portuguese, Italian, German, Russian, Japanese, Chinese, etc. |
|
Support OS |
Windows ,HDMI, Android, ect. |
|
Power Supply |
|
|
External Power Supply |
AC 100 - 240V, 50-60Hz |
|
Working voltage |
DC 12-24V |
|
Power consumption |
≤35W |
|
Enclosure |
|
|
Material |
Aluminum Alloy |
|
Color |
Black, Silver or customized |
|
VESA mounting |
75x75mm/100x100mm |
|
IP grade |
Front panel IP55 waterproof |
|
Operating Environment |
|
|
Temperature Range |
operating: -10 to 50°C, storage: -20 to 80°C |
|
Relative humidity |
operating: -5% to 95%, storage: -5% to 95% |
|
Packing Details |
|
|
Gross weight |
about 4kg |
|
Accessories |
Power adapter, VGA cable, USB touch cable, embedded screws |
|
Other |
|
|
Mounting |
embedded mounting screws |
|
wall mounting brackets (optional) |
|
|
desk stand holder (optional) |
|
|
Warranty |
1 year warranty |
|
Certificates |
CE, 3C, RoHS |
